• Fault self-checking and alarm prompt functions for easy maintenance
• Standard card reader window with external switch/remote control options
• Automatic reset function with adjustable delay (3S, 5S, 10S, 60S)
• Anti-collision and anti-tailgating functions
• Automatic gate drop when power is off for fire safety compliance
• Compatible with multiple card reading devices and relay switch signals
• Optical working principle prevents multiple passes per card swipe
• External button controls for left/right normally open function
• Remote management capability via computer (customizable)
• Counting function available to record attendance (customizable)

• Shell material: 304 stainless steel frame (customizable to 201 stainless steel or iron paint)
• Processing technology: Bending, cutting, welding, polishing, grinding
• Standard dimensions: 280 * 1200 * 980mm
• Weight: Approximately 70Kg
• Gate rod length: 510mm
• Maximum bearing capacity: 80Kg
• Working driving force: 3Kg
• Steering options: One-way or two-way
• Light prompt: High-brightness traffic status indication
• Working movement: 12V/20W solenoid valve
• Working environment: Indoor/outdoor (canopy recommended)
• Temperature range: -40℃ to 80℃
• Gate opening time: 0.2 seconds
• Passing speed: Approximately 30 people/minute
• Standard input interface: Relay switch signal

Innovation Pass adheres to the business philosophy of "integrity, innovation, and brand". With more than ten years of experience in intelligent channel gate systems, we break traditional patterns with new design concepts, offering high-tech channel products including brushless swing gates, brushless three-roller gates, brushless wing gates, and high-end sliding gates.

Our products are used nationwide in banks, foreign companies, large state-owned enterprises, administrative units, petrochemical oil fields, passenger stations, mobile communications, prisons, smart communities, shopping malls, office buildings, and tourist attractions.
